HNA 600
HNA 600 Jointing Sheets are designed with a premium blend of aramid fibre, glass fibre, and NBR, engineered to provide high resistance under heavy stress and aggressive media conditions. This advanced gasket material ensures reliable sealing performance in applications exposed to oil, water, gases, and chemicals, while offering enhanced strength and durability thanks to its glass fibre reinforcement. HNA 600 is ideal for industrial machinery and equipment operating in demanding environments, including compressors, pipelines, pumps, gas meters, and internal combustion engines.
Technical Specifications
- Conforms to Standards: ASTM F36A, ASTM F146, DIN 52911, DIN 3535, DIN 52913
- Max Peak Temperature: 440°C
- Max Continuous Temperature: 250°C
- Max Operating Pressure: 100 Kg./CM²
Typical Applications
- Compressors
- Pipelines
- Gas meters
- Internal combustion engines
- Pump systems
Key Features
- Made with aramid fibre, glass fibre, and NBR for maximum durability
- High resistance to oil, water, gases, and aggressive chemicals
- Withstands peak temperature up to 440°C
- Performs reliably under continuous 250°C conditions
- Handles operating pressure up to 100 Kg./CM²
- Designed for high stress industrial environments
Available Sizes
- 0.5mm x 1.27mtr x 1.27mtr
- 1.0mm x 1.27mtr x 1.27mtr
- 1.5mm x 1.27mtr x 1.27mtr
